Vonghler V1160L

TECHNICAL SPECIFICATIONS

Category Parameter Unit V1160L
Spindle Spindle Motor Type - Direct Drive
Spindle Taper - BBT40
Maximum Spindle Speed rpm 12000
Spindle Power kW 18
Spindle Torque N·m 118
Working Area X/Y/Z Axis Travels mm 1100 / 610 / 610
Distance from Spindle Nose to Table mm 150–760
Table Table Size mm 1200 × 600
T-slot (size × quantity × spacing) mm 18 × 5 × 100
Maximum Table Load kg 1000
Feed Feed Rate (X/Y/Z) m/min 32 / 32 / 24
Accuracy X/Y/Z Axis Positioning Accuracy mm 0.008
X/Y/Z Axis Repeatability mm 0.005
Tool Magazine Tool Magazine Type / Capacity - Arm Type / 24T
Maximum Tool Size mm

Vonghler V1160L

The Vonghler V1160L vertical machining center combines German-inspired engineering principles with smart and efficient manufacturing technologies. Thanks to its mineral casting machine structure, it delivers exceptional rigidity, superior vibration damping, and long-term geometric stability for highly precise and repeatable machining performance.

Offered to the Turkish market with the assurance of GNC Makina, the Vonghler VL Series provides a cost-effective solution suitable for a wide range of manufacturing applications.

Key Features

  • Mineral Casting Technology
    Provides significantly better vibration damping and thermal stability compared to steel and cast iron structures.
  • High Rigidity & Stability
    Monoblock structure and optimized column design ensure stable machining even under heavy cutting conditions.
  • Long-Term Precision
    Low thermal expansion minimizes the effects of temperature fluctuations.
  • Superior Surface Quality
    Reduced vibration improves surface finish and extends tool life.
  • Wide Application Range
    Suitable for machining aluminum, steel, difficult alloys, and mold applications.
  • GNC Makina After-Sales Support
    Nationwide service network, fast response times, and expert technical support across Türkiye.

TECHNICAL SPECIFICATIONS

Category Parameter Unit V1160L
Spindle Spindle Motor Type - Direct Drive
Spindle Taper - BBT40
Maximum Spindle Speed rpm 12000
Spindle Power kW 18
Spindle Torque N·m 118
Working Area X/Y/Z Axis Travels mm 1100 / 610 / 610
Distance from Spindle Nose to Table mm 150–760
Table Table Size mm 1200 × 600
T-slot (size × quantity × spacing) mm 18 × 5 × 100
Maximum Table Load kg 1000
Feed Feed Rate (X/Y/Z) m/min 32 / 32 / 24
Accuracy X/Y/Z Axis Positioning Accuracy mm 0.008
X/Y/Z Axis Repeatability mm 0.005
Tool Magazine Tool Magazine Type / Capacity - Arm Type / 24T
Maximum Tool Size mm
