Victor Taichung Vturn-V560

TECHNICAL SPECIFICATIONS

Items Unit V560 (2 Axis) V560 (C Axis)
Capacity
Swing over carriage dia mm Ø540 Ø540
Standard turning dia mm Ø470 Ø520
Maximum turning dia mm Ø560 Ø610
Max. turning length mm 532 470
Main Spindle
Max speed rpm 2500 2500
Nose (chuck) inch A2-8 (12") A2-8 (12")
Turret
NO. of tools (live) T 8 12
Shank size mm □32 □25
Machine
Weight kg 6100 6100

Victor Taichung Vturn-V560

The Victor Taichung V560 is a vertical CNC turning center designed to deliver high stability and precision under heavy-duty machining conditions. With its large machining capacity and robust construction, it enables efficient and controlled machining of large workpieces. Its high-rigidity structure minimizes vibration, allowing superior surface quality and consistent machining results.

The V560 is an ideal solution for manufacturers seeking high production performance and long-term operational stability in heavy-duty turning applications.

Key Features

  • Vertical turning design enables stable machining of large and high-volume workpieces
  • High-rigidity machine structure provides excellent stability during heavy cutting operations
  • Powerful and controlled spindle performance ensures superior surface finish and precise machining results
  • Large machining capacity offers advantages in the production of oversized parts
  • User-friendly CNC control system simplifies programming and machine operation
  • Victor Taichung engineering delivers a durable and long-lasting machine design

TECHNICAL SPECIFICATIONS

Items Unit V560 (2 Axis) V560 (C Axis)
Capacity
Swing over carriage dia mm Ø540 Ø540
Standard turning dia mm Ø470 Ø520
Maximum turning dia mm Ø560 Ø610
Max. turning length mm 532 470
Main Spindle
Max speed rpm 2500 2500
Nose (chuck) inch A2-8 (12") A2-8 (12")
Turret
NO. of tools (live) T 8 12
Shank size mm □32 □25
Machine
Weight kg 6100 6100
