Victor Taichung Vcenter-P106

Get a Quote
Catalog

TECHNICAL SPECIFICATIONS

Items Unit P106 (Non CTS) P106 (CTS)
Travel
X axis mm 1060 1060
Y axis mm 600 600
Z axis mm 560 560
Table
Work area mm 1120 × 520 1120 × 520
T-slot mm 5 × 18 × 100 5 × 18 × 100
Max load kg 600 600
Spindle
Quill taper   BBT-40 BBT-40
Motor power kW 11 / 15 / 18.5 7.5 / 11 / 15
Max speed rpm 12000 12000
Tools
Capacity T 30 30
Max weight kg 7 7
Accuracy (ISO 230-2)
Accuracy mm 0.01 0.01
Repeatability mm 0.007 (±0.0035) 0.007 (±0.0035)
Machine
Weight kg 6450 6450

Victor Taichung Vcenter-P106

The Victor Vcenter P106 is a CNC machining center developed to deliver high stability, reliability, and continuous performance for daily manufacturing needs. Thanks to its rigid machine structure and balanced design, it ensures consistent machining quality even during long production cycles. The P106 is an ideal solution for manufacturers seeking efficient, trouble-free, and predictable production processes in general manufacturing, mass production, and environments involving various workpiece types.

Key Features

  • Structure Designed for Production Continuity
    Balanced and robust construction developed for intensive and long-term operations.
  • Stable Machining Performance
    Vibration-free and reliable machining characteristics that preserve part quality.
  • User-Friendly Operation
    Practical operation and easy control designed to support operator habits and efficiency.
  • Wide Range of Applications
    Effective solution for general manufacturing, mass production, and precision part machining applications.
  • Strong Price / Performance Balance
    Optimizes investment costs without compromising production efficiency.

TECHNICAL SPECIFICATIONS

Items Unit P106 (Non CTS) P106 (CTS)
Travel
X axis mm 1060 1060
Y axis mm 600 600
Z axis mm 560 560
Table
Work area mm 1120 × 520 1120 × 520
T-slot mm 5 × 18 × 100 5 × 18 × 100
Max load kg 600 600
Spindle
Quill taper   BBT-40 BBT-40
Motor power kW 11 / 15 / 18.5 7.5 / 11 / 15
Max speed rpm 12000 12000
Tools
Capacity T 30 30
Max weight kg 7 7
Accuracy (ISO 230-2)
Accuracy mm 0.01 0.01
Repeatability mm 0.007 (±0.0035) 0.007 (±0.0035)
Machine
Weight kg 6450 6450
