ONA AD35

TECHNICAL SPECIFICATIONS

X-axis travel	600 mm	23.622 in
Y-axis travel	400 mm	15.748 in
Z-axis travel	290 mm	11.417 in
Maximum workpiece dimensions - Length	990 mm	38.976 in
Maximum workpiece dimensions - Width	620 mm	24.409 in
Maximum workpiece dimensions - Height	290 mm	11.417 in
U-V axes travel	100 mm × 100 mm	3.937 × 3.937 in
Max. Taper	±21° / 100 mm	±30° / 3.937 in
Wire size range	0.2 mm – 0.25 mm – 0.3 mm	0.078 in – 0.0984 in – 0.118 in
Max. Axes speed	800 mm/min	31.49 in/min
Best Roughness	0.4 Ra	0.2 µm Ra

ONA AD35

The ONA AD35 is a compact industrial CNC Wire-EDM machine designed to deliver maximum precision, high productivity, and reliable performance in wire erosion applications. With its larger workpiece capacity, advanced AD Series technology, and user-friendly control system, it provides an efficient solution for mold manufacturing, precision part production, and prototyping applications.

Its modern Windows-style CNC interface, integrated automation support, and energy-efficient structure help accelerate production processes, reduce operator errors, and lower total operating costs.

Key Features

Advanced precision cutting technology ensuring accurate and reliable Wire-EDM performance
Windows-style graphical interface offering user-friendly operation and automation support
Laser-tested according to VDI 3441 and ISO 230-4 standards for positioning and circular accuracy
Repeatable machining precision across different machines using identical cutting parameters
Low maintenance cost and extremely low energy consumption for efficient long-term operation
Standard collision protection system enhancing machine safety and operational reliability

TECHNICAL SPECIFICATIONS

X-axis travel	600 mm	23.622 in
Y-axis travel	400 mm	15.748 in
Z-axis travel	290 mm	11.417 in
Maximum workpiece dimensions - Length	990 mm	38.976 in
Maximum workpiece dimensions - Width	620 mm	24.409 in
Maximum workpiece dimensions - Height	290 mm	11.417 in
U-V axes travel	100 mm × 100 mm	3.937 × 3.937 in
Max. Taper	±21° / 100 mm	±30° / 3.937 in
Wire size range	0.2 mm – 0.25 mm – 0.3 mm	0.078 in – 0.0984 in – 0.118 in
Max. Axes speed	800 mm/min	31.49 in/min
Best Roughness	0.4 Ra	0.2 µm Ra
